XTR-MD Series

Corrosion-resistant Rotary Valve for Abrasive or Acidic Materials

The XTR-MD Series valve boasts high corrosion resistance with the same efficient, high-performance design of our popular round-flange MD Series rotary valve. It is specially outfitted to excel in any pressure pneumatic conveying system that requires food-grade product contact.

Get a quote

Downloads Datasheet Brochure

Features & Benefits:

Cast iron housing and endplates coated with XTR-Coat, a chemically-resistant coating.
Resists wear and corrosion from chemicals, acid and abrasive material.
XTR-Coat also prevents material sticking and buildup on valve surfaces.
USDA and FDA compliant.
Mild steel or stainless steel rotor machined with precision for tight tolerances.
Rated for great performance in operating temperatures up to 500°F.

What to do if your valve becomes uncompliant (Because it will)

ACS now offers XTR-Coat synergistic coatings to maximize performance in a variety of applications. XTR-Coat finishes provide wear and corrosion protection, reduced friction and non-stick performance. XTR-Coat finishes are a high-performance, non-toxic and FDA-compliant alternative to industrial chrome plating.

Handles pressure differentials up to 15 PSIG.
Available sizes: Round flange 4" through 16".
Expedites cleaning and sanitation operations; works well in washdown duty environments.
Non-stick, food-grade properties for sugar, flour, pet food and other food processing applications.
Dry-lubricity.
Non-porous, moisture-proof surfaces and mold release.

Rotary Valve Capacity (Cubic Feet/Hr.)

8	12	60	96	120	144	168	192	216	240	264
10	24	120	192	240	288	336	384	432	480	528
12	45	225	360	450	540	630	720	810	900	990
	1	5	8	10	12	14	16	18	20	22
	Rotor Speed (RPM)
