AN-X Dust Collector

Dust Collector Valve for airlock applications

The AN-X Valve is an NFPA compliant dust collector valve for any application. Complete with steel rotor tips and outboard bearings, this valve is great for easy, drop-in replacements for FT or AN dust collection valves.

Get a quote

Downloads Datasheet Technical Drawing (DWG)

Features & Benefits:

Mild Steel construction
Rotor with steel rotor tips
Heavy-duty construction
Direct-drive operation
Tight internal clearances
ACST-4™ glandless Teflon® shaft seal
8-vane rotor
NFPA compliant
Steel tips
Outboard bearings
Easy drop-in replacements

Valve	Rotary Valve Capacity (Cubic Feet/Revolution)
	8"	0.64
	10"	1.34
	12"	2.46

Customizations: AN-X Dust Collector

Rotors

Open End Rotor

Specifications

Inlet/Outlet Flange Sizes: 3 sizes: 8", 10", 12"

Material of Construction: Mild Steel or Stainless Steel

Pressure Differential: Up to 15 psi

High Temperature Range: 500^°F

Industries

Pharmaceutical and Cosmetics

Systems

Types

Airlock with metering

Metering / Feeding

Rotary Airlock

Try the valve sizing tool
